Product Overview
This 10.8V 7800mAh high-capacity lithium-ion battery pack features a 3S3P configuration using LIC18650 cylindrical cells. With 9 premium 18650 cells for high voltage and substantial capacity.
Key Features
* 3S3P High-Capacity Design — Nine 18650 cells deliver 7800mAh at 10.8V — enough power for full-day operation
* High Discharge Capability — 3P parallel configuration supports higher current draw with lower per-cell stress
* LIC18650 Premium Cells — Grade A Li-ion cylindrical cells with consistent capacity and low internal resistance
* Cell-Level Protection — Each parallel group monitored for balanced charge/discharge and extended pack lifespan
* Robust Industrial Construction — Reinforced shrink-wrap package with vibration-resistant cell holders
* Advanced BMS — Multi-point protection: cell balancing, overcharge, over-discharge, over-current, short circuit, temperature
* Custom Connector & Packaging — Available with Anderson, XT60, Deans, or custom power connectors
Technical Specifications
Nominal Voltage | 10.8V |
Rated Capacity | 7800mAh (84.24Wh) |
Cell Type | Li-ion (LIC) LIC18650 |
Configuration | 3S3P |
Charge Voltage | 12.6V |
Discharge Cut-off | 9.0V |
Max Continuous Discharge | 2C (15600mA) |
Cycle Life | ≥500 cycles |
Protection Circuit | Overcharge, Over-discharge, Cell Balancing, Short Circuit, Temperature |
Charge Temp | 0°C ~ 45°C |
Discharge Temp | -20°C ~ 60°C |
