Product Overview
This 7.6V 3600mAh high-voltage lithium polymer battery pack uses a 2S1P configuration with advanced LP525880 pouch cells. The 3.8V/cell HV Li-Po chemistry delivers 5-10% higher energy density than standard 3.7V Li-Po.
Key Features
* High-Voltage Li-Po Technology — 3.8V/cell nominal delivers higher energy density (27.36Wh total) than standard 3.7V Li-Po
* Ultra-Slim LP525880 Cells — Slim 5.2mm thickness enables integration into thin-profile devices
* 2S1P 7.6V Configuration — Stable voltage output for electronics requiring >5V supply rails
* Premium Grade A Cells — Consistent quality with minimal internal resistance variation
* Built-in Protection (PCM) — Multi-layer safety: overcharge, over-discharge, over-current, and thermal protection
* Customizable Form Factor — Available with various connector and packaging options
* UN38.3 Transport Certified — Safe for air, sea, and land freight
Technical Specifications
Nominal Voltage | 7.6V |
Rated Capacity | 3600mAh (27.36Wh) |
Cell Type | HV Li-Polymer LP525880 |
Configuration | 2S1P |
Charge Voltage | 8.7V |
Discharge Cut-off | 6.0V |
Max Continuous Discharge | 1C (3600mA) |
Cycle Life | ≥500 cycles |
Protection Circuit | Overcharge, Over-discharge, Short Circuit, Over-current |
Charge Temp | 0°C ~ 45°C |
Discharge Temp | -20°C ~ 60°C |
Applications: Premium Smartphones, Tablet PCs, Portable Medical Devices, Handheld Gaming, Wearables
